Control Common Properties
The following properties are common to all controls:
Property |
Name1 |
Description |
Type1 |
Get1 |
Set1 |
Control name |
ctrl |
The control name. All names within a form/component must be unique. |
Character |
Yes |
No |
Display only |
displayOnly |
Makes the control and all of its children display only i.e. data cannot be entered. A control is considered to be display only if the control or any of its parents have been set as display only. |
Boolean |
Yes |
Yes |
Hidden |
hidden |
Hides the control and all of its children. A control is considered to be hidden if the control or any of its parents have been set as hidden. |
Boolean |
Yes |
Yes |
Message options |
|
Provides options to control where messages are displayed and their appearance. See message options for details. |
|
|
|
Modifiers |
modifiers |
Modifiers should be entered as a comma delimited list of
individual modifiers e.g. Audit, Supervisor, Mod2 Level1 Modifiers provide a way
of flagging one or more controls so they can be found programatically, e.g. a
group of Field Controls might be changed from enterable to display only. Any
number of modifiers can be assigned - Modifiers are accessed by using method Page.getControlsByModifier(). Javascript example: var page = pages.PAGE_1; for each (var ctrl in page.getControlsByModifier("Audit")) { if (!system.securityManager.hasRole("FINANCE_CONTROLLER")) { ctrl.hide(); } } |
Character |
Yes |
Yes |
New Line |
newLine |
When inside a container with Field Grid layout, indicates that the control should be placed on a new line. This property is only shown for controls that support the new line option. See Field Grid Layout for more information. |
Boolean |
Yes |
Yes |
Html Element Properties |
|
Provides support for the creation of rich client applications, allows the creation of: locators, event handlers and custom attributes. Click here for more details. |
|
|
|
Events |
|
Allows all events for the control to be configured. Displays the events dialog. |
|
No |
No |
1 See accessing control properties from scripts
Click on the … button to display the Styling Assistant for the control. Details of the properties available with each styling assistant are shown in the documentation for each control – see Controls.
